Item Number:
Microprocessor controlled MIG-MAG/FLUX/BRAZING/MMA/TIG DC-Lift inverter multiprocess welding machine.
Technomig is confirmed as the perfect solution for a wide range of applications, from maintenance to installation and interventions in body shops, because of its flexibility and the different materials it can weld (steel, stainless steel, aluminium), or braze weld (galvanized sheet).
The fast SYNERGIC adjustment of the welding parameters thanks to the “ONE TOUCH” technology, makes the product very easy to use. Just set the material thickness and start welding: the intelligent and automatic control of the arc, moment by moment, maintains high welding performance in all working conditions, with different materials and/or gases.
The operator can also intervene manually along the arc length: this adjustment means the weld seam can be modified according to the welder’s style.
Lightweight and very compact, Technomig can be moved around easily in all intervention areas, both indoors and outdoors.
Features:
– Polarity reversal for GAS MIG-MAG/BRAZING welding;
– Thermostatic, overvoltage, undervoltage, motorgenerator (+/- 15%) protections;
– Arc-force adjustment in MMA;
– Euro torch connection.
Complete with MIG-MAG torch, work clamp and cable.
816075
SINGLE PHASE MAINS VOLTAGE
230 V
MAINS FREQUENCY
50 / 60 HZ
CURRENT RANGE
20 – 170 A
MAX CURRENT
140 @ 20% A
DC CURRENT
80 A
MAX NO LOAD VOLTAGE
44 V
MAX ABSORBED CURRENT
22 A
ABSORBED CURRENT AT 60%
11 A
MAX ABSORBED POWER
3,2 KW
ABSORBED POWER AT 60%
1,6 KW
EFFICIENCY
86 %
POWER FACTOR
0,7
D. USABLE ELECTRODES IN DC
1,6-3,2 MM
STEEL WELDING WIRE DIAMETER
0,6 – 0,8 MM
INOX WELDING WIRE DIAMETER
0,8 MM
ALUMINIUM WELDING WIRE DIAM.
0,8 – 1 MM
FLUX CORED WELDING WIRE DIAM.
0,8 – 1,2 MM
BRAZING WIRE DIAM.
0,8 MM
PROTECTION DEGREE
IP23
DIMENSIONS
46 X 24 X 36 CM
WEIGHT
11, kg
1 unit
DIMENSIONS
46 X 24 X 36 CM
WEIGHT
11, kg
Supplied Accessories:
MT15 Mig Torch Red 3m (742180)
CABLE TW05V-A 1X025 1.80M PLUG ATLAS (124589)
TOLEDO 250 WORK CLAMP 250A (712030)
